Which network cable types does the HD Extender support? HD Extender is a video signal that can be extended and transmitted to a large screen 70 or 100 meters away for display. HDBaseT technology transmits high-definition digital signals. The transmission process has no delay and no compression, and supports 4K ultra-high-definition display effects. It supports 3D display and is widely used in long-distance transmission of video signals in conference rooms.

Which network cable types does the HD Extender support? It mainly supports 3 kinds of network cables, Category 5e network cable

Category 6 network cable

Category 6e network cable

The Cat5e network cable has low attenuation, less crosstalk, higher attenuation to crosstalk ratio (ACR) and signal-to-noise ratio (Structural Return Loss), and smaller delay error, and the performance is greatly improved. Category 6 network cable, an important difference between Category 6 and Category 5e is that in terms of crosstalk and return loss performance, for the use of a new generation of full-duplex high-speed networks, excellent return loss performance is extremely important. important. Category 6e network cable is an improved version of Category 6 network cable, which has greatly improved in crosstalk, attenuation and signal-to-noise ratio.

The HD Extender does not have very high requirements on the network cable, and can solve some wiring problems in the field of use. The power supply function of POC can realize image transmission only by supplying power at one end. It is a good solution for long-distance transmission in conference rooms when used with HDBaseT boards of high-definition hybrid matrix switcher.
