4K30 seamless switcher 8x1 with IR and RS232

4K30 seamless switcher 8x1 with IR and RS232 is a HDMI 4K seamless and scaling switcher, supports automatic switching and manual switching, supports switching from 4 or 8 HDMI inputs to 1 HDMI output, and 8 HDMI inputs support different arbitrary resolutions with seamless switching and scaling.

inquiry

Introduction

4K30 seamless switcher 8x1 with IR and RS232t is a HDMI 4K seamless and scaling switcher, supports automatic switching and manual switching, supports switching from 4 or 8 HDMI inputs to 1 HDMI output, and 8 HDMI inputs support different arbitrary resolutions with seamless switching and scaling. The HDMI output supports fixed resolutions output, which can be selected through the front panel buttons, infrared remote control, and RS232 serial port commands. Also supports EDID management through RS232 commands.




Real shot products

  • 8x1-seamless-switcher-4K30-with-IR-and-RS232
  • 8x1-switcher-4K30-with-seamless-IR-and-RS232
  • seamless-8x1-switcher-4K30-with-IR-and-RS232
  • seamless-switcher-8x1-4K30-with-IR-and-RS232



  • Features

    · Support HDMI1.4, and the resolution up to 3840*2160@30Hz

    · Support CEC, ARC follow

    · Support seamless switching even when different resolutions inputs;

    · Support auto and manual switching modes

    · Support the front panel push-button, IR remote and the RS232 control

    ·Support EDID management by RS232 commands

    ·Support work and standby power saving modes

    ·Support work and standby power saving modes

    Technical Parameters

    Tyoe SW-4K30-81S
    Description HDMI 4K30 8x1 seamless switcher
    Input 8X HDMI
    Output 1*HDMI+3.5mm audio
    Protocol Standard HDMI1.4, HDCP1.4
    Resolution
    (8)3840*2160@30\1920*1080@60\1280*720@60\1366*768@60
    Dimension
    Weight
    0.5kg(1.1lb)(No packing)
    Power Supply
    DC 12V 1A
    Consumption
    2.5W
    Working Humidity
    10%-90%
    Temperature
    -10℃-50℃
    Storage
    -20℃-75℃

    Connection diagram

    seamless-switcher-8x1-4K30-with-IR-and-RS232-connection-diagram
