4K30 HDMI Fiber Optic Extender consists of transmitter and receiver, with a mini chassis and single core LC connectors, it allows to be used in a narrow space but for a long distance transmission applications.
inquiry
4K30 HDMI Fiber Optic Extender consists of transmitter and receiver, with a mini chassis and single core LC connectors, 4K30 HDMI Fiber Optic Extender allows to be used in a narrow space but for a long distance transmission applications. And the resolution can up to 3840*2016/30Hz (YUV 4:4:4) or 3840*2016/60Hz (YUV 4:2:0), 4K30 HDMI Fiber Optic Extender also can support the HDMI 1.4 and HDCP1.4 compliant. standard, the transmission distance can up to 300m over OM3 MMF and SMF
· Resolution up to 3840*2160/30Hz(Y:U:V 4:4:4) or 3840*2160/30Hz(Y:U:V 4:2:0)
· Distance can up to 300 meters over OM3 MMF or SMF Fiber
· Support HDMI1.4 and HDCP compliant
· LC connector, use 1-core OM3 MM Fiber or SM fiber cable
· Micro USB-B power connector
· Data security with negligible RFI/EMI emissions
· MINI chassis for narrow space applications
Tyoe
FIBER-HD-110-T
FIBER-HD-110-R
Description
Mini HDMI Fiber Optic transmitter
Mini HDMI Fiber Optic receiver
Input
1×HDMI, 1×DC
1×LC Fiber Optic, 1×DC
Output
1×LC Fiber Optic
1×HDMI
Standard Protocol
Supports HDMI 1.4 and compatible HDCP 1.4
Resolution
Up to 4K@30Hz
Distance
300m at single model Fiber cable
Dimension
59.5x20x10.5(mm)(Tx/Rx)/ 2.34x0.78x0.41（inch)
Weight
80g(Tx/Rx) 0.17lbs
Power Supply
AC：110-240V 50/60Hz 1.5A Max DC：12V 1500mA
Power consumption
5W
Working Temperature
0℃-50℃
Storage Temperature
﹣20℃-55℃
No.
Name
Qty
Unit
1
Fiber-HD-110T
1
Pcs.
2
Fiber-HD-110R
1
Pcs
3
DC 12V2A Power Adapter
1
Pcs
