In a real application, users usually need to send one DVI signal to the display, meanwhile also need one more extra to monitor. So 1 to 4 DVI splitter comes to solve this issue. It supports 1 DVI/ HDMI input and 4 DVI/ HDMI outputs, the resolution can up to 1920*1200@ 60Hz, the maximum resolution can up to 4K with smart EDID management. Compatible with DVI1.0, the transmission distance can reach 15 meters
inquiry
In a real application, users usually need to send one DVI signal to the display, meanwhile also need one more extra to monitor. So 1 to 4 DVI splitter comes to solve this issue. It supports 1 DVI/ HDMI input and 4 DVI/ HDMI outputs, the resolution can up to 1920*1200@ 60Hz, the maximum resolution can up to 4K with smart EDID management. Compatible with DVI1.0, the transmission distance can reach 15 meters
· Supports 1 DVI input and 4 outputs
· Transmission distance can up to 15 meters
· Supports 1920*1200@60Hz, the maximum can reach4K2K;
· Compatible with DVI1.0, HDCP protocol;
· Smart EDID management function;
·Visual LED indicators
| Tyoe |
DVI-1*4 |
| Description |
1 to 4 DVI Spliiter with EDID management |
| Input |
1×DVI |
| Output |
4×DVI |
| Protocol Standard |
Support DVI1.0, HDCP, EDID management |
|
Resolution |
Support 1920*1200@ 60Hz, the maximum 4K2K |
| Dimension |
272*98*44mm |
|
Weight |
1kg(No packing) |
|
Power Supply |
AC 110V-240V 50/60Hz |
|
Consumption |
≤11W |
|
Working Humidity |
10%-90% |
|
Temperature |
-10℃-50℃ |
|
Storage |
-20℃-75℃ |
|
No. |
Name |
Qty |
Unit |
|
1 |
SPL-DVI-0104E |
1 |
Pcs. |
|
2 |
power Cord |
1 |
Pcs |
|
3 |
Rack ear |
1 |
Pcs |
