4x4 4K30 HDMI Seamless Matrix Switcher With 2x2 Video Wall

This is a new fixed 4x4 HDMI matrix switcher series with the seamless switch, Video Wall function, EDID management, audio breakouts and the resolution can up to 4K30Hz with scaling funtion and all ports are HDCP compliant.

inquiry

4K30Hz 4X4 HDMI Matrix Switcher demo video


4K30Hz 4X4 HDMI Matrix Switcher Introduction

This is a new fixed 4x4 HDMI matrix switcher series with the seamless switch, Video Wall function, EDID management, audio breakouts and the resolution can up to 4K30Hz with scaling funtion and all ports are HDCP compliant. With the friendly user control methods: IR remote control, 2-Press push buttons with background blue light, WEB GUI/TCPIP/RS232/IR remote control, supports the WEB smart EDID management, this matrix switcher can work with the Blu-Ray Players, Set-Top boxes, Home Theater, and game consoles etc HDMI input sources to route to the HDMI displays, it has been widely used in different audio visual applications.


4K60 4x4 HDMI Matrix Switcher pictures

  • 4x4-4K30-Seamless-Matrix-Switcher-With-2x2-Video-Wall-Controller-audio-visual-equipment-manufacturers2
  • 4x4-4K30-Seamless-Matrix-Switcher-With-2x2-Video-Wall-Controller-audio-visual-equipment-manufacturers22
  • 4x4-4K30-Seamless-Matrix-Switcher-With-2x2-Video-Wall-Controller-audio-visual-equipment-manufacturers212
  • 4x4-4K30-Seamless-Matrix-Switcher-With-2x2-Video-Wall-Controller-audio-visual-equipment-manufacturers2222



  • 4K30 4x4 HDMI Matrix switcher Features

    · 4*HDMI1.4 with 4*3.5mm audio Inputs

    · 4*HDMI1.4 with 4*3.5mm audio

    · Seamless switching

    · Supports Matrix switching, Video Wall

    · Supports audio independently switching

    · Compliant HDCP 2.2 with EDID management

    · Control by front-panel push buttons, IR Remote, RS232, TCP/IP and APP

    · Supports up to 16 scenes

    · Supports to rename the inputs, outputs and sence

    4K30 4x4 HDMI Matrix switcher Technical Parameters

    Tyoe SVM-MANAGER-400A-4K30
    Resolution

    4K@30Hz/1080P/1080i/720P

    Input

    4*HDMI2.0 with 4*3.5mm audio in

    Output

    4*HDMI2.0 with 4*3.5mm audio out

    Standard Protocol Supports HDMI1.4
    Transmission distance

    10m/30ft for 4K30, 15m/45ft for 1080P@60Hz(by qualified HDMI cables)

    Controlling

    Front-panel push buttons, IR Remote, RS232, TCP/IP and APP

    Bandwidth

    18Gbps

    Weight 2kg/4.41Lbs
    Size

    440*279*44 mm/17.32x10.98x1.73 Inch

    Power Supply

    24 V/2 A DC (US/EU standards, CE/FCC/UL certified)

    Power consumption 36W(max)
    Working Temperature

    0 ºC~40 ºC/32 ºF~104 ºF

    Storage Temperature

    −20 ºC~60 ºC/−4 ºF~140 ºF

    4K60 4x4 HDMI Matrix switcher Packing list

    No.

    Name

    Qty

    Unit

    1

    SVM-MANAGER-400A-4K30

    1

    Pcs.

    2

    DC 24V2A power adapter

    1

    Pcs

    3

    Remote Control(without battery)

    1

    Pcs

    4

    Mounting ears

    1

    Pair


    4K30 4x4 HDMI Matrix switcher Connection diagram


    4x4-4K60-18Gbps-HDMI2.0-Seamless-Matrix-Switcher-With-Video-Wall,-Multi-Viewer-and-Scaler-functions-audio-visual-equipment-supplier11
