This product is a HDMI 4K60 4x1 KVM switcher, supports automatic switching and manual switching, supports switching from 4 HDMI inputs to 1 HDMI output, and 4 HDMI inputs support different arbitrary resolutions, support front panel buttons, infrared remote control, and RS232 serial port commands and KVM hotkey switching. Also supports EDID management through RS232 commands.
inquiry
This product is a HDMI 4K60 4x1 KVM switcher, supports automatic switching and manual switching, supports switching from 4 HDMI inputs to 1 HDMI output, and 4 HDMI inputs support different arbitrary resolutions, support front panel buttons, infrared remote control, and RS232 serial port commands and KVM hotkey switching. Also supports EDID management through RS232 commands.
· Support HDMI 2.0, HDCP2.2, USB2.0
· The maximum resolution is 4K60HZ and the speed is up to 18G
· Support multiple keyboard hotkey switching;
· Support HDMI sound separation output;
· Support EDID to improve compatibility and match signal sources and display devices;
·Support automatic switching, manual switching, priority switching, etc.
·Support RS232 control
·Built-in ESD protection circuit, easy installation, plug and play
| Tyoe | SW-4K30-81S |
| Description | HDMI 4K30 4x1 seamless switcher with KVM |
| Input | 4X HDMI,4USB-B |
| Output |
1*HDMI+3.5mm audio, 1USB-A |
| Protocol Standard | HDMI1.4, HDMICP1.4 |
|
Resolution |
(8)3840*2160@30\1920*1080@60\1280*720@60\1366*768@60 |
| Dimension |
214X138X43MM |
|
Weight |
0.5kg(1.1lb)(No packing) |
|
Power Supply |
DC 12V 1A |
|
Consumption |
5W |
|
Working Humidity |
10%-90% |
|
Temperature |
-10℃-50℃ |
|
Storage |
-20℃-75℃ |
|
No. |
Name |
Qty |
Unit |
|
1 |
SW-4K30-41SKVM |
1 |
Pcs. |
|
2 |
DC 12V2A power adapter |
1 |
Pcs |
|
3 |
Remote Control(without battery) |
1 |
Pcs |
