4x1 4K60 HDMI Multiviewer Quad Screen w/ PIP Audio（Discontinued）

4x1 4K60 HDMI Multiviewer is a 4x1 HDMI Multiviewer Switcher with 4 HDMI inputs and 1 HDMI output, the input2 can support up to 4K60, the HDMI output can up to 4K60 output with scaling function.

inquiry

Product details

4x1 4K60 HDMI Multiviewer Introduction

4x1 4K60 HDMI Multiviewer is a 4x1 HDMI Multiviewer Switcher with 4 HDMI inputs and 1 HDMI output, the input2 can support up to 4K60, the HDMI output can up to 4K60 output with scaling function, 4x1 4K60 HDMI Multiviewer support multiple working modes, fast switching between the sources and point to point display. 4x1 4K60 HDMI Multiviewer also can support the Window/audio selection and switching, RS232/remote/push-button control, users also can save/recall 4 presets accordingly. With the pure hardware design, 4x1 4K60 HDMI Multiviewer is more stable, easy to install and friendly use. 4x1 4K60 HDMI Multiviewer can be popularly used in different projects, such as the conference room, medical, education etc.

4x1 4K60 HDMI Multiviewer pictures

4K60-4x1-HDMI-Multiviewer-RS232&scenes&-scaling

4K60-4x1-HDMI-Multiviewer-with-picture-in-picture-and-window-size-adjustment-by-RS232-control

Multiple-working-modes-4K60-4x1-HDMI-Multiviewer

4x1 4K60 HDMI Multiviewer Features

· Supports Four 4K HDMI inputs, and one 4K60 HDMI output

· Compatible with HDMI2.0, HDMI1.4 and HDCP2.2 and HDCP1.4

· Output resolution can up to 4K@60Hz with scaling

· Support audio de-embedded function

· Supports PIP function and window size adjustment by RS232 control

4x1 4K60 HDMI Multiviewer Technical Parameters

Tyoe	VPX-401-4K60
Description	4K60 4x1 HDMI multiviewer switcher
Input	1x4K60 HDMI, 3x 4K30 HDMI
Output signals	1x 4K60 HDMI
Protocol	DP1.2, HDMI2.0, HDCP2.2
Bandwidth	18GBps
Dimension	1909227(mm)/7.873.621.06 inch
Weight	400g/0.88lbs
Power Supply	AC:110V-240V 50-60Hz, DC：12V 1.5A
Working Temperature	0℃-50℃
Storage Temperature	﹣20℃-55℃
